EFL80-9-HV-PRO8000 kg
EFL80-9-HV-PRO High-Capacity Electric Forklift (8.0 t, 80 V HV)
High-voltage (309 V) electric counterbalance forklift replacing 8 t IC trucks — 8.0 t capacity at 900 mm load centre with 60 kW drive and zero emissions indoors.
Capacity
8000 kg
Drive
Electric
Max Lift Height
7000 mm
Travel Speed
29/30 km/h
Gradeability
22/28 %
Service Weight
13900 kg
Battery
309V/314AhV/Ah
Full Specifications
Specification format follows VDI 2198 (industrial trucks) with energy data per DIN EN 16796.
Basic Data
Manufacturer
EP
Model designation
EFL80-9-HV-PRO
Drive
Electric
Operator type
Seated
Rated capacity
8000 kg
Load centre distance
900 mm
Load distance, centre of drive axle to fork
718 mm
Service weight
13900 kg
Tyres
Pneumatic
Wheels, number front/rear (x=drive wheels)
4x/2
Drive motor rating S2 60 min
60 kW
Type of drive unit
PMSM
Sound pressure level at the driver's seat
/ dB(A)
Dimensions
Wheelbase
2500 mm
Axle loading, laden front/rear
19250/2650 kg
Axle loading, unladen front/rear
6090/7810 kg
Tyre size, front
9.00-20-14PRmm
Tyre size, rear
9.00-20-14PRmm
Tread width, front
1600 mm
Tread width, rear
1700 mm
Tilt of mast/fork carriage forward/backward
6/12 °
Height, mast lowered
2850 mm
Free lift
205 mm
Lift
3000 mm
Height, mast extended
4310 mm
Height of overhead guard (cabin)
2560 mm
Seat height relating to SIP/stand height
1550 mm
Coupling height
630 mm
Overall length
5785 mm
Overall width
2200 mm
Fork dimensions
85×160×1820 mm
Fork carriage width
2130 mm
Ground clearance, laden, below mast
250 mm
Ground clearance, centre of wheelbase
295 mm
Aisle width for pallets 1000×1200 crossways
6343 mm
Aisle width for pallets 800 × 1200 lengthways
6343 mm
Turning radius
3605 mm
Lift speed, laden/unladen
0.42/0.47 m/s
Lift motor rating at S3 15%
78.5 kW
Max lift height
7000 mm
Performance
Travel speed, laden/unladen
29/30 km/h
Lowering speed, laden/unladen
0.46/0.40 m/s
Max. drawbar pull, laden/unladen
/N
Max. gradeability, laden/unladen
22/28 %
Service brake
Mechanical/Hydraulic
Parking brake
Mechanical
Drive & Battery
Battery voltage/nominal capacity
309V/314AhV/Ah
Battery weight
850 kg
Energy consumption according to DIN EN 16796
/ ¹⁾kWh/h
Charger output current
/ A
Operation & Environment
Oil volume for attachments
/ℓ/min
Steering design
Hydraulic
Length to face of forks
3965 mm
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
