RPL201 Heavy-Duty Ride-On Pallet Truck (2.0 t)
Ride-on pallet truck with 2.0 t capacity and a standing platform — 8 km/h travel speed cuts long-haul transport time while keeping operator comfort.
Capacity
2000 kg
Drive
Electric
Max Lift Height
120 mm
Travel Speed
7.5/8 km/h
Gradeability
8/16 %
Service Weight
670 kg
Battery
Li-Ion (24 V)
Full Specifications
Specification format follows VDI 2198 (industrial trucks) with energy data per DIN EN 16796.
Basic Data
Manufacturer
EP
Model designation
RPL201
Drive
Electric
Operator type
Standing
Rated capacity
2000 kg
Load centre distance
600 mm
Load distance, centre of drive axle to fork
980 mm
Service weight
670 kg
Tyres
Polyurethane
Wheels, number front/rear (x=drive wheels)
1x+2/4/1x+2/2
Drive motor rating S2 60 min
1.6 kW
Type of drive unit
AC
Sound pressure level at the driver's seat
74 dB(A)
Dimensions
Wheelbase
1418 mm
Axle loading, laden front/rear
1060/1610 kg
Axle loading, unladen front/rear
540/130 kg
Tyre size, front
Ф230x75mm
Tyre size, rear
Ф85x70/Ф83x115mm
Additional wheels (castor wheels)
Ф130x55mm
Tread width, front
510 mm
Tread width, rear
370/515 mm
Max lift height
120 mm
Lift
["120"] mm
Height drawbar in driving position min./max.
1075/1288 mm
Height, lowered
85 mm
Overall length
1860 mm
Overall width
734 mm
Fork dimensions
55x170x1150 mm
Distance between fork-arms
540 / 685 mm
Ground clearance, centre of wheelbase
30 mm
Aisle width for pallets 1000×1200 crossways
2500 mm
Aisle width for pallets 800 × 1200 lengthways
2360 mm
Turning radius
1700 mm
Lift speed, laden/unladen
0.050/0.054 m/s
Lift motor rating at S3 15%
2.2 kW
Performance
Travel speed, laden/unladen
7.5/8 km/h
Lowering speed, laden/unladen
0.067/0.054 m/s
Max. gradeability, laden/unladen
8/16 %
Service brake
Electromagnetic
Drive & Battery
Battery voltage
24 V
Battery nominal capacity K5
205 Ah
Battery type
Li-Ion
Battery weight
62 kg
Operation & Environment
Steering design
Electronic
Length to face of forks
710 mm
Specifications are subject to change without notice due to continuous product improvement. Confirm final parameters with our sales team for your order.
